Bike computer with graphics LCD screen

I’ve designed a complete new hardware & software for the bicycle comp that I’ve published some months ago. This one has a 128X64 monochrome graphics screen instead of the 16×2 character display of the former one.

the product on the handlebar

the product on the handlebar

the product on the handlebar

the product on the handlebar

this has got real time clock as well as the temperature sensor like the old one. But all data can either be shown fully digital or two different analog display modes.

on off switch

on off switch





Read More

Mp3 player holder for bikes

I’d published a product  for mounting mp3 players to bikes some months ago. Recently I’ve resized it, converted its locking mechanism to a double lock for added strength and printed one, by using an UP printer. I’ve assembled it to my folding bike with the mp3 player that i’ve bought from the market for just 14$. The design turned out to be nice, performed its duty well, holding the mp3 player in place at the same time directing its sounds towards the rider. Though the speakers of the player were at the sides, the sound was being distributed to the sides and music was a bit difficult to hear without redirection.

side view

side view

front view

front view

now sound is good. The STL files are at the end of the article for the ones who want to print their own product.

Read More

SteamPunk Clock

steampunk clock

screenshot from solidworks

The creation of this article is a kitsch product that looks and pretends to be like a steam engine.

But within the body, there is microprocessor power and a graphics LCD screen that can display various clock faces.

It can generate a number of  sound effects suitable for the current clock graphic displayed on the LCD.

The body is suitable to be produced at a 3D printer.

Read More
